| Artikelnummer | C-51505NFJ-SLW-APN |
| Marke | Kyocera |
| Größe | 3.0 |
| Anwendung | |
| Auflösung | 20×2 |
| Komposition | LCM |
| Helligkeit | |
| CR | 5:1 |
| Farben | Monochrome |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU |
| Panel-Marke | Kyocera |
| Panel-Modell | C-51505NFJ-SLW-APN 3 Compatible model |
| Plattentyp | FSTN-LCD , LCM |
| Panelgröße | 3.0 inch |
| Anzeigeformat | 20 characters × 2 lines |
| Anzeigemodus | STN, Black/White (Positive), Transflective |
| Schriftarten anzeigen | 5×8 dots |
| Zeichengröße | 3.235×5.585 mm |
| Charakterhöhe | 3.8×5.95 mm |
| aktiver Bereich | 75.435×11.535 mm |
| Lünettenbereich | 83.0×18.6 mm |
| Umriss | 116×37×15.9 mm |
| Helligkeit | |
| Kontrastverhältnis | 5:1 (Typ.)(Transmissive) |
| Farben anzeigen | Monochrome |
| Reaktionszeit | 80/110 (Typ.)(Tr/Td) |
| Lampentyp | 1 pcsWLEDWithout Driver |
| Signalschnittstelle | 8-bit parallel, 16 pins |
| Eingangsspannung | 5.0V (Typ.) |
| 30WQF0H | SII | 3.0 | 240×400 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| A030JTN01.1 | AUO | 3.0 | 960×480(dot) |
| C-51505NFJ-SLG-AHN | Kyocera | 3.0 | 20×2 |
| C-51505NFJ-SLW-AIN | Kyocera | 3.0 | 20×2 |
| C-51505NFJ-SLW-APN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LB-AJN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LG-AKN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LW-ALN | Kyocera | 3.0 | 20×2 |
| LH300WQ1-ED01 | LG Display | 3.0 | 240×400 |
| AL2004A | Other | 3.0 | 20×4 |
| LQ150X1LGN1 | SHARP | 15.0 | 1024×768 |
| LQ61D133 | SHARP | 6.1 | 640×480 |
| LTA065A040F | TOSHIBA | 6.5 | 640×480 |
| LTA150B850F | TOSHIBA | 15.0 | 1024×768 |
| LTM10C345 | TOSHIBA | 10.4 | 1024×768 |
| LTS200QC-F0V | Samsung | 2.0 | 176×220 |
| OEL9M0083-B-E | Other | 0.96 | 128×64 |
| OEL9M0083-W-E | Other | 0.96 | 128×64 |
| PD104VT3H1 | E Ink | 10.4 | 640×480 |
