| Artikelnummer | C-51505NFJ-SLG-AHN |
| Marke | Kyocera |
| Größe | 3.0 |
| Anwendung | |
| Auflösung | 20×2 |
| Komposition | LCM |
| Helligkeit | |
| CR | 5:1 |
| Farben | Monochrome |
| Hintergrundbeleuchtung | G-LED |
| Schnittstelle | CPU |
| Panel-Marke | Kyocera |
| Panel-Modell | C-51505NFJ-SLG-AHN 1 Compatible model |
| Plattentyp | FSTN-LCD , LCM |
| Panelgröße | 3.0 inch |
| Anzeigeformat | 20 characters × 2 lines |
| Anzeigemodus | STN, Black/White (Positive), Transflective |
| Schriftarten anzeigen | 5×8 dots |
| Zeichengröße | 3.235×5.585 mm |
| Charakterhöhe | 3.8×5.95 mm |
| aktiver Bereich | 75.435×11.535 mm |
| Lünettenbereich | 83.0×18.6 mm |
| Umriss | 116×37×15.9 mm |
| Helligkeit | |
| Kontrastverhältnis | 5:1 (Typ.)(Transmissive) |
| Farben anzeigen | Monochrome |
| Reaktionszeit | 80/110 (Typ.)(Tr/Td) |
| Lampentyp | 1 pcsG-LEDWithout Driver |
| Signalschnittstelle | 8-bit parallel, 16 pins |
| Eingangsspannung | 5.0V (Typ.) |
