| Artikelnummer | TFTMD030035 |
| Marke | JDI |
| Größe | 3.0 |
| Anwendung | HHP |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | 410 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | JDI |
| Panel-Modell | TFTMD030035 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 3.0 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 60×45 mm |
| Umriss | 70.7×52×2.75 mm |
| Oberfläche | Hard coating |
| Helligkeit | 410 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193184% |
| Reaktionszeit | 20/20 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| Eingangsspannung | (1.8/3.0)/3.0V (Typ.)(VDDIO/VDD) |
| Anwendung | HHP |
