| Artikelnummer | H546TAN01.0 |
| Marke | AUO |
| Größe | 5.5 |
| Anwendung | MPH |
| Auflösung | 720×1280 |
| Komposition | LCM |
| Helligkeit | 440 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | H546TAN01.0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.5 inch |
| Auflösung | 720(RGB)×1280 , WXGA |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 68.04×120.96 mm |
| Umriss | 72.3×130.39×1.75 mm |
| Oberfläche | |
| Helligkeit | 440 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 35 (Max.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes) |
| Eingangsspannung | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| Anwendung | MPH |
