| Artikelnummer | CT022TN15 |
| Marke | Innolux |
| Größe | 2.2 |
| Anwendung | MPH |
| Auflösung | 176×220 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 300:1 |
| Farben | 65K/262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU |
| Panel-Marke | INNOLUX |
| Panel-Modell | CT022TN15 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.2 inch |
| Auflösung | 176(RGB)×220 , QCIF+ |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 34.848×43.56 mm |
| Umriss | 42.3×57.5 mm |
| Oberfläche | |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 65K/262K , CIE193150% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 55/55/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4S1PWLEDWithout Driver |
| Signalschnittstelle | CPU, 20 pins |
| Eingangsspannung | 3.3/3.3V (Typ.)(VDD/VCI) |
| Anwendung | MPH |
