| Artikelnummer | BTL507212-W746L |
| Marke | BOE |
| Größe | 5.0 |
| Anwendung | MPH |
| Auflösung | 720×1280 |
| Komposition | LCM |
| Helligkeit | |
| CR | 700:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | BOE |
| Panel-Modell | BTL507212-W746L |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.0 inch |
| Auflösung | 720(RGB)×1280 , WXGA |
| Anzeigemodus | ADS, Normally Black, Transmissive |
| aktiver Bereich | 62.1×110.4 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | 700:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 27 pins |
| Eingangsspannung | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| Anwendung | MPH |
