| Artikelnummer | TM022HDH31 |
| Marke | Tianma |
| Größe | 2.2 |
| Anwendung | MPH |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 500:1 |
| Farben | |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU |
| Panel-Marke | TIANMA |
| Panel-Modell | TM022HDH31 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.2 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 33.84×45.12 mm |
| Umriss | 38.88×53.44 mm |
| Oberfläche | |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | |
| Reaktionszeit | |
| Blickwinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | WLED |
| Anwendung | MPH |
