| Artikelnummer | LH550WF4-SD01 |
| Marke | LG Display |
| Größe | 5.5 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | Assembly |
| Helligkeit | 550 |
| CR | 1600:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | LG Display |
| Panel-Modell | LH550WF4-SD01 |
| Plattentyp | LTPS TFT-LCD , Assembly |
| Panelgröße | 5.5 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| aktiver Bereich | 68.364×121.536 mm |
| Umriss | 75.27×155.55×2.35 mm |
| Oberfläche | |
| Helligkeit | 550 cd/m² (Typ.) |
| Kontrastverhältnis | 1600:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | MIPI (4 data lanes), 36 pins |
| Eingangsspannung | 1.8//5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
| Anwendung | MPH |
