| Artikelnummer | H546DLB01.1 |
| Marke | AUO |
| Größe | 5.5 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | OLED |
| Helligkeit | 350 |
| CR | 10000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | self |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | H546DLB01.1 |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 5.5 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| aktiver Bereich | 68.04×120.96 mm |
| Umriss | 70.84×128.01 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 10000 : 1 (Min.) |
| Farben anzeigen | 16.7M (8-bit), CIE1931103% |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥1600)(L/R/U/D) |
| Treiber-IC | COG Built-in RM69070 |
| Signalschnittstelle | MIPI (2 data lanes), 40 pins |
| Eingangsspannung | 1.8/3.0/4.6/7.6V (Typ.)(IOVCC/VCI/OVDD/AVDD) |
| Anwendung | MPH |
