| Artikelnummer | BT043NHME601 |
| Marke | BOE |
| Größe | 4.3 |
| Anwendung | MPH |
| Auflösung | 360×600 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | |
| Panel-Marke | BOE |
| Panel-Modell | BT043NHME601 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 4.3 inch |
| Auflösung | 360(RGB)×600 , nHD |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 55.62×92.7 mm |
| Umriss | 59.4×101.9 mm |
| Oberfläche | Without Polarizer |
| Glastiefe | 0.30+0.30 mm |
| Durchlässigkeit | 4.8% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193160% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| Anwendung | MPH |
