| Artikelnummer | ACX425AKM |
| Marke | SONY |
| Größe | 3.7 |
| Anwendung | MPH |
| Auflösung | 480×800 |
| Komposition | LCM |
| Helligkeit | 320 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SONY |
| Panel-Modell | ACX425AKM |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 3.7 inch |
| Auflösung | 480(RGB)×800 , WVGA |
| Anzeigemodus | Normally Black, Transmissive |
| aktiver Bereich | 48.24×80.4 mm |
| Umriss | 53.9×90 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 320 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193190% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 7S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| Eingangsspannung | 2.6/2.6V (Typ.)(VDD/AVDD) |
| Anwendung | MPH |
