| Artikelnummer | LH500WF3-SH01 |
| Marke | LG Display |
| Größe | 5.0 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | |
| Panel-Marke | LG Display |
| Panel-Modell | LH500WF3-SH01 |
| Plattentyp | LTPS TFT-LCD , CELL |
| Panelgröße | 5.0 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| Anzeigemodus | AH5-IPS, Normally Black, Transmissive |
| aktiver Bereich | 61.884×110.016 mm |
| Umriss | 63.884×116.596 mm |
| Oberfläche | Without Polarizer |
| Glastiefe | 0.15+0.15 mm |
| Durchlässigkeit | 2.8% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Treiber-IC | COG Suggest NT35596 |
| Anwendung | MPH |
