| Artikelnummer | H598QAN01.0 |
| Marke | AUO |
| Größe | 6.0 |
| Anwendung | MPH |
| Auflösung | 1440×2560 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | H598QAN01.0 |
| Plattentyp | LTPS TFT-LCD , CELL |
| Panelgröße | 6.0 inch |
| Auflösung | 1440(RGB)×2560 , Quad-HD |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 74.52×132.48 mm |
| Umriss | 76.32×138.88×0.62 mm |
| Oberfläche | Hard coating |
| Durchlässigkeit | 3.6% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 20/15 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Treiber-IC | COG Built-in NT35598 |
| Anwendung | MPH |
| BA060WV1-100 CELL | BOE | 6.0 | 480×854 |
| ED060SC1 | E Ink | 6.0 | 800×600 |
| ED060SCC | E Ink | 6.0 | 600×800 |
| ED060SCM | E Ink | 6.0 | 600×800 |
| ED060SCN | E Ink | 6.0 | 600×800 |
| H598QAN01.0 | AUO | 6.0 | 1440×2560 |
| LB060S01-FD01 | LG Display | 6.0 | 800×600 |
| LB060X02-RD01 | LG Display | 6.0 | 1024×768 |
| TFD60W20MS | TOSHIBA | 6.0 | 320×240 |
| TM060RDH01 | Tianma | 6.0 | 800×480 |
| DLC0220KZG | Other | 2.2 | 320×320 |
| LH400WS1-SD03 | LG Display | 4.0 | 640×1136 |
| LH400WV3-SD02 | LG Display | 4.0 | 480×800 |
| LH450WX3-SD01 | LG Display | 4.5 | 720×1280 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LPM055A138A | JDI | 5.5 | 1440×2560 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| TM045XDZP08 | Tianma | 4.5 | 540×960 |
