| Artikelnummer | LS025A8DZ01S |
| Marke | SHARP |
| Größe | 2.5 |
| Anwendung | DSC |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 310 |
| CR | 400:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | SHARP |
| Panel-Modell | LS025A8DZ01S |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 2.5 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | ASV, Normally Black, Transflective |
| aktiver Bereich | 49.9×37.4 mm |
| Oberfläche | Hard coating (2H) |
| Helligkeit | 310 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 25/25 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDWithout Driver |
| Signalschnittstelle | Serial RGB (8-bit), 45 pins |
| Eingangsspannung | 3.3V (Typ.)(VDD) |
| Anwendung | DSC |
