| Artikelnummer | PA025XSB |
| Marke | E Ink |
| Größe | 2.5 |
| Anwendung | DSC |
| Auflösung | 480×234 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 350:1 |
| Farben | Full color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog |
| Panel-Marke | PVI |
| Panel-Modell | PA025XSB |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.5 inch |
| Auflösung | 480×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 49.68×37.44 mm |
| Umriss | 61.6×49.3×6.1 mm |
| Oberfläche | Antiglare |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 350:1 (Typ.) |
| Farben anzeigen | Full color |
| Reaktionszeit | 15/25 (Typ.)(Tr/Td) |
| Blickwinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | TFT Specific Analog RGB, 28 pins |
| Eingangsspannung | 5.0/5.0/5.0/15.0/-12.0V (Typ.)(VCC/VDD/AVDD/VGH/VGL) |
| Anwendung | DSC |
