| Artikelnummer | TM027CDH04 |
| Marke | Tianma |
| Größe | 2.7 |
| Anwendung | DSC |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 350:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | TIANMA |
| Panel-Modell | TM027CDH04 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.7 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 54×40.5 mm |
| Umriss | 63.5×46.6×2.8 mm |
| Oberfläche | Clear, Hard coating (3H) |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 350:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193140% |
| Reaktionszeit | 25/40 (Typ./Max.)(Tr+Td) |
| Blickwinkel | 50/50/25/55 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 2S1PWLEDWithout Driver |
| Signalschnittstelle | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | DSC |
| A027DN03 V2 | AUO | 2.7 | 320×240 |
| H027QT01 | AUO | 2.7 | 208×320 |
| LS027B7DH01 | SHARP | 2.7 | 400×240 |
| OEL9M5001-B-E | Other | 2.7 | 128×64 |
| OEL9M5003-Y-E | Other | 2.7 | 128×64 |
| RGS27128064YW000 | RiTdisplay | 2.7 | 128×64 |
| TM027CDH02 | Tianma | 2.7 | 320×240 |
| TM027CDH04 | Tianma | 2.7 | 320×240 |
| TM027CDH12 | Tianma | 2.7 | 320×240 |
| TM027CDH19 | Tianma | 2.7 | 320×240 |
| A027DN01 V1 | AUO | 2.7 | 320×240 |
| A027DN03 V4 | AUO | 2.7 | 320×240 |
| A030DN01 VC | AUO | 3.0 | 320×240 |
| A030DW01 V3 | AUO | 3.0 | 320×240 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LQ035Q1DH02 | SHARP | 3.5 | 320×240 |
| LS025A8DZ01S | SHARP | 2.5 | 320×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| TM035KDH03-36 | Tianma | 3.5 | 320×240 |
| UP018D11 | UNIPAC | 1.8 | 528×220(dot) |
