| Artikelnummer | AMS465GS53 |
| Marke | Samsung |
| Größe | 4.7 |
| Anwendung | MPH |
| Auflösung | 720×1280 |
| Komposition | Assembly |
| Helligkeit | 300 |
| CR | 3400:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | self |
| Schnittstelle | MIPI |
| Panel-Marke | SAMSUNG |
| Panel-Modell | AMS465GS53 |
| Plattentyp | AM-OLED , Assembly |
| Panelgröße | 4.7 inch |
| Auflösung | 720RG(BG)×1280 , WXGA |
| aktiver Bereich | 57.96×103.04 mm |
| Umriss | 66.36×131.8 mm |
| Oberfläche | Hard coating |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 3400 : 1 (Min.) |
| Farben anzeigen | 16.7M (8-bit), CIE1931100% |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | MIPI (4 data lanes), 44 pins |
| Eingangsspannung | 2.2/3.1/3.8V (Typ.)(VDD3/VCI/VBAT) |
| Anwendung | MPH |
