| Artikelnummer | LS047T1SC02 |
| Marke | SHARP |
| Größe | 4.7 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | LCM |
| Helligkeit | 470 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | SHARP |
| Panel-Modell | LS047T1SC02 |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 4.7 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| Anzeigemodus | New Mode2, Normally Black, Transmissive |
| aktiver Bereich | 57.996×103.104 mm |
| Umriss | 60.4×112.2×1.48 mm |
| Oberfläche | |
| Helligkeit | 470 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193171% |
| Reaktionszeit | 35 (Max.)(Tr+Td) |
| Blickwinkel | |
| Frequenz | 60Hz |
| Lampentyp | 2 stringsWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 31 pins |
| Eingangsspannung | 5.0/-5.0/1.8V (Typ.)(AVDD/AVEE-/IOVCC) |
| Anwendung | MPH |
