| Artikelnummer | AT056TN52 V.3 |
| Marke | Innolux |
| Größe | 5.6 |
| Anwendung | DPF |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | INNOLUX |
| Panel-Modell | AT056TN52 V.3 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.6 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 112.896×84.672 mm |
| Umriss | 126.5×100×6 mm |
| Oberfläche | Antiglare |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 10/15 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S5PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit), 50 pins |
| Eingangsspannung | 3.3/5.0/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| Anwendung | DPF |
