| Artikelnummer | AT056TN03 |
| Marke | Innolux |
| Größe | 5.6 |
| Anwendung | VDP |
| Auflösung | 320×234 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 300:1 |
| Farben | |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog |
| Panel-Marke | INNOLUX |
| Panel-Modell | AT056TN03 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.6 inch |
| Auflösung | 320(RGB)×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 113.28×84.708 mm |
| Umriss | 126.5×100 mm |
| Oberfläche | |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | |
| Reaktionszeit | 15/20 (Typ.)(Tr/Td) |
| Blickwinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | TFT Specific Analog RGB, 26 pins |
| Eingangsspannung | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| Anwendung | VDP |
