| Artikelnummer | A080SN01 V8 |
| Marke | AUO |
| Größe | 8.0 |
| Anwendung | DPF |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 500:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | AUO |
| Panel-Modell | A080SN01 V8 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.0 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 162×121.5 mm |
| Umriss | 183×141 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| Reaktionszeit | 4/16 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S8PWLEDWithout Driver |
| Signalschnittstelle | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| Eingangsspannung | 3.3/11.68/15/-6.75V (Typ.)(VCC/AVDD/VGH/VGL) |
| Anwendung | DPF |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| A080SN01 V8 | AUO | 8.0 | 800×600 |
| A080SN02 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V2 | AUO | 8.0 | 800×600 |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| DJ080PA-01C | Innolux | 8.0 | |
| PW080XU4 | E Ink | 8.0 | 480×220 |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| CLAA070MA21BW | CPT | 7.0 | 800×600 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| HSD100IFW1-C01 | HannStar | 10.1 | 1024×600 |
| LQ070Y3DG01 | SHARP | 7.0 | 800×480 |
| LQ085Y3DG12 | SHARP | 8.5 | 800×480 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
