| Artikelnummer | A080SN03 V2 |
| Marke | AUO |
| Größe | 8.0 |
| Anwendung | DPF |
| Auflösung | 800×600 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 500:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | TTL |
| Panel-Marke | AUO |
| Panel-Modell | A080SN03 V2 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 8.0 inch |
| Auflösung | 800×600(RGB) , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 162×121.5 mm |
| Umriss | 170.1×132.3 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Glastiefe | 0.50+0.50 mm |
| Durchlässigkeit | 4.88% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + Dithering), CIE193150% |
| Reaktionszeit | 12/18 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | TTL (1 ch, 8-bit) + SPI, 60 pins |
| Eingangsspannung | 3.3/5/-5/14/-14V (Typ.)(VDDIO/VDPA/VDNA/VGH/VGL) |
| Anwendung | DPF |
