| Artikelnummer | A080SN01 V0 |
| Marke | AUO |
| Größe | 8.0 |
| Anwendung | DPF |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 400:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | AUO |
| Panel-Modell | A080SN01 V0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.0 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 162×121.5 mm |
| Umriss | 183×141 mm |
| Oberfläche | Antiglare |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 400:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 6-bit + Dithering) |
| Reaktionszeit | 4/16 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S8PWLEDWithout Driver |
| Signalschnittstelle | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| Eingangsspannung | 3.3/11.6/15/-6.75V (Typ.)(VCC/AVDD/VGH/VGL) |
| Anwendung | DPF |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| A080SN01 V8 | AUO | 8.0 | 800×600 |
| A080SN02 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V2 | AUO | 8.0 | 800×600 |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| PD080SL3 | E Ink | 8.0 | 800×600 |
| PW080XU4 | E Ink | 8.0 | 480×220 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A070SN01 V3 | AUO | 7.0 | 800×600 |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| AT102TN03 V.1 | Innolux | 10.2 | 800×480 |
| CLAA070MA21BW | CPT | 7.0 | 800×600 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| LQ070Y3DG04 | SHARP | 7.0 | 800×480 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
