| Artikelnummer | A080SN01 V5 |
| Marke | AUO |
| Größe | 8.0 |
| Anwendung | DPF |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 500:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | AUO |
| Panel-Modell | A080SN01 V5 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.0 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 162×121.5 mm |
| Umriss | 183×141 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| Reaktionszeit | 4/16 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S8PWLEDWithout Driver |
| Signalschnittstelle | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| Eingangsspannung | 3.3/11.68/15/-6.75V (Typ.)(VCC/AVDD/VGH/VGL) |
| Anwendung | DPF |
