| Artikelnummer | LTP280QV-E01 |
| Marke | Samsung |
| Größe | 2.8 |
| Anwendung | MPH |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 110 |
| CR | 150:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTP280QV-E01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.8 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 43.2×57.6 mm |
| Umriss | 52.9×71.7×4.75 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 110 cd/m² (Typ.) |
| Kontrastverhältnis | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit), CIE193130% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 61 pins |
| Eingangsspannung | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| Anwendung | MPH |
