| Artikelnummer | LQ056A3AG01 |
| Marke | SHARP |
| Größe | 5.6 |
| Anwendung | |
| Auflösung | 320×234 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 60:1 |
| Farben | Full color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog |
| Panel-Marke | SHARP |
| Panel-Modell | LQ056A3AG01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.6 inch |
| Auflösung | 320(RGB)×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 114.2×83.5 mm |
| Umriss | 140×102.7 mm |
| Oberfläche | |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 60:1 (Min.) |
| Farben anzeigen | Full color |
| Reaktionszeit | 15/20 (Typ.)(Tr/Td) |
| Blickwinkel | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLEmbedded (Inverter) |
| Signalschnittstelle | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| Eingangsspannung | 12.0V (Typ.) |
