| Artikelnummer | LSUGC202XA |
| Marke | ALPS |
| Größe | 8.9 |
| Anwendung | |
| Auflösung | 640×240 |
| Komposition | LCM |
| Helligkeit | 160 |
| CR | 3:1 |
| Farben | Monochrome |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Parallel Data |
| Panel-Marke | ALPS |
| Panel-Modell | LSUGC202XA |
| Plattentyp | STN-LCD , LCM |
| Panelgröße | 8.9 inch |
| Auflösung | 640×240 , HVGA |
| Anzeigemodus | STN, Blue mode |
| aktiver Bereich | 211.18×79.18 mm |
| Umriss | 270.2×112.2 mm |
| Oberfläche | |
| Helligkeit | 160 cd/m² (Typ.) |
| Kontrastverhältnis | 3 : 1 (Typ.) |
| Farben anzeigen | Monochrome |
| Reaktionszeit | 250/120 (Typ.)(Tr/Td) |
| Blickwinkel | 30/30/15/30 (Min.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | Parallel Data (4-bit), 12 pins |
