| Artikelnummer | LH470WX6-SD02 |
| Marke | LG Display |
| Größe | 4.7 |
| Anwendung | MPH |
| Auflösung | 750×1334 |
| Komposition | LCM |
| Helligkeit | |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | |
| Panel-Marke | LG Display |
| Panel-Modell | LH470WX6-SD02 |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 4.7 inch |
| Auflösung | 750(RGB)×1334 , WXGA |
| Anzeigemodus | AH3-IPS, Normally Black, Transmissive |
| aktiver Bereich | 58.5×104.052 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 35 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLED |
| Anwendung | MPH |
