| Artikelnummer | COM35T3112DTR |
| Marke | ORTUSTECH |
| Größe | 3.5 |
| Anwendung | HHP |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 100 |
| CR | 60:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | CASIO |
| Panel-Modell | COM35T3112DTR |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 52.56×70.08 mm |
| Umriss | 67.9×84.5×5.4 mm |
| Oberfläche | |
| Helligkeit | 100 cd/m² (Typ.) |
| Kontrastverhältnis | 60:1 (Min.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 40/60 (Max.)(Tr/Td) |
| Blickwinkel | 50/50/60/20 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit), 45 pins |
| Eingangsspannung | 3.0V (Typ.) |
| Anwendung | HHP |
