| Artikelnummer | AMCB004 |
| Marke | Samsung |
| Größe | 2.4 |
| Anwendung | MPH |
| Auflösung | 240×320 |
| Komposition | OLED |
| Helligkeit | 200 |
| CR | 30000:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | self |
| Schnittstelle | CPU |
| Panel-Marke | SAMSUNG SDI |
| Panel-Modell | AMCB004 |
| Plattentyp | AM-OLED , OLED |
| Panelgröße | 2.4 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| aktiver Bereich | 36.72×48.96 mm |
| Umriss | 42.32×58.42 mm |
| Oberfläche | Antiglare, Hard coating (2H) |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 30000 : 1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE1931106% |
| Blickwinkel | 90/90/90/90 (Max.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | CPU, 31 pins |
| Eingangsspannung | 3.0/3.8V (Typ.)(VDD/Vbat) |
| Anwendung | MPH |
| AMC162A | Other | 2.3 | 16×2 |
| AMC162B | Other | 2.3 | 16×2 |
| AMCB004 | Samsung | 2.4 | 240×320 |
| AMCE002 | Samsung | 2.4 | 240×320 |
| C0240QGLG-T | CMEL | 2.4 | 240×320 |
| DMC-16117A | Kyocera | 2.4 | 16×1 |
| LS024Q8DD92 | SHARP | 2.4 | 240×320 |
| PD024OX4 | E Ink | 2.4 | 480×234 |
| RGS24128022YR000 | RiTdisplay | 2.4 | 128×22 |
| TM024HBZ26 | Tianma | 2.4 | 240×320 |
| BB050HDG-T40 | BOE | 5.0 | 720×1280 |
| ET0320A5DM9 | EDT | 3.2 | 240×320 |
| HSD015F4N2-B | HannStar | 1.5 | 128×128 |
| LQ043T1LX01A | SHARP | 4.3 | 540×960 |
| LS020B8UD02 | SHARP | 2.0 | 176×220 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| RGS15128128FH035 | RiTdisplay | 1.46 | 128×128 |
| TM032PDZ17 | Tianma | 3.2 | 320×480 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
| TX08D13VM0AAA | KOE | 3.0 | 240×400 |
