| Artikelnummer | TM035PDH53 |
| Marke | Tianma |
| Größe | 3.5 |
| Anwendung | MPH |
| Auflösung | 320×480 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 500:1 |
| Farben | 65K/262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB |
| Panel-Marke | TIANMA |
| Panel-Modell | TM035PDH53 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×480 , HVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 48.96×73.44 mm |
| Umriss | 54.34×84.07×2.1 mm |
| Oberfläche | Clear |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 65K/262K , CIE193160% |
| Reaktionszeit | 20 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 6S1PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB, 45 pins |
| Eingangsspannung | 1.8/2.8 (Typ.)(IOVCC/VCC) |
| Anwendung | MPH |
