| Artikelnummer | PA035XSL |
| Marke | E Ink |
| Größe | 3.5 |
| Anwendung | DSC |
| Auflösung | 320×234 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 350:1 |
| Farben | Full color |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Analog |
| Panel-Marke | PVI |
| Panel-Modell | PA035XSL |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 71.6×52.65 mm |
| Umriss | 83.5×63.1×3.9 mm |
| Oberfläche | Antiglare |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 350:1 (Typ.) |
| Farben anzeigen | Full color |
| Reaktionszeit | 15/25 (Typ.)(Tr/Td) |
| Blickwinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S2PWLEDWithout Driver |
| Signalschnittstelle | TFT Specific Analog RGB, 30 pins |
| Eingangsspannung | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD/AVDD/VGH/VGL) |
| Anwendung | DSC |
| 35WVF1H | SII | 3.5 | 480×800 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| AM-320240LATNQW-T00H-F | AMPIRE | 3.5 | 320×240 |
| LQ035Q7DB02R | SHARP | 3.5 | 240×320 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| PA035XSL | E Ink | 3.5 | 320×234 |
| PD035VX8 | E Ink | 3.5 | 480×640 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| T-51963GD035J-MLW-AJN | Kyocera | 3.5 | 240×320 |
| TX09D70VM1CEA | KOE | 3.5 | 240×320 |
| 990000738A | Innolux | 3.5 | 320×240 |
| CT025TN01 | Innolux | 2.5 | 320×240 |
| LH250Q01-TH02 | LG Display | 2.5 | 320×240 |
| LMS350GF07-005 | Samsung | 3.5 | 320×240 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| LTV350QV-F05 | Samsung | 3.5 | 320×240 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| PD035OX4 | E Ink | 3.5 | 320×234 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035KDH08 | Tianma | 3.5 | 320×240 |
