| Artikelnummer | NL10276AC30-07 |
| Marke | NLT |
| Größe | 15.0 |
| Anwendung | DMPC |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 300:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | NEC |
| Panel-Modell | NL10276AC30-07 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.0 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | Normally Black, Transmissive |
| aktiver Bereich | 304.128×228.096 mm |
| Umriss | 330×256×30 mm |
| Oberfläche | Hard coating (2H) |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Reaktionszeit | 10/10 (Typ.)(Tr/Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 8 pcsCCFLEmbedded (Inverter) |
| Signalschnittstelle | TTL (2 ch, 8-bit), 75 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | DMPC |
