| Artikelnummer | NL10276AC28-05R |
| Marke | NLT |
| Größe | 14.1 |
| Anwendung | DMPC |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 220 |
| CR | 150:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | NEC |
| Panel-Modell | NL10276AC28-05R |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 14.1 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 285.696×214.272 mm |
| Umriss | 330×255×20.5 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 220 cd/m² (Typ.) |
| Kontrastverhältnis | 150:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193140% |
| Reaktionszeit | 11/40 (Typ.)(Tr/Td) |
| Blickwinkel | 50/50/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 2 pcsCCFLEmbedded (Inverter) |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 20 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | DMPC |
