| Artikelnummer | LTL097QL01-W01 |
| Marke | Samsung |
| Größe | 9.7 |
| Anwendung | PAD |
| Auflösung | 2048×1536 |
| Komposition | LCM |
| Helligkeit | 420 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | eDP |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTL097QL01-W01 1 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 9.7 inch |
| Auflösung | 2048(RGB)×1536 , QXGA |
| Anzeigemodus | PLS, Normally Black, Transmissive |
| aktiver Bereich | 196.608×147.456 mm |
| Umriss | 208.88×167.12×5.02 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| Helligkeit | 420 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 16 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDWithout Driver |
| Signalschnittstelle | eDP (4 Lanes), 51 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
