| Artikelnummer | TV080X0M-NS0 |
| Marke | BOE |
| Größe | 8.0 |
| Anwendung | PAD |
| Auflösung | 768×1024 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 900:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | BOE |
| Panel-Modell | TV080X0M-NS0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.0 inch |
| Auflösung | 768(RGB)×1024 , XGA |
| Anzeigemodus | ADS, Normally Black, Transmissive |
| aktiver Bereich | 121.882×162.509 mm |
| Umriss | 128.142×173.739 mm |
| Oberfläche | |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193171% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 8S3PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 34 pins |
| Eingangsspannung | 1.8/5.4/-5.4V (Typ.)(Vio/Vsn/Vsp) |
| Anwendung | PAD |
