| Artikelnummer | LP097QX3-SPAV |
| Marke | LG Display |
| Größe | 9.7 |
| Anwendung | PAD |
| Auflösung | 1536×2048 |
| Komposition | Assembly |
| Helligkeit | 400 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | eDP |
| Panel-Marke | LG Display |
| Panel-Modell | LP097QX3-SPAV |
| Plattentyp | a-Si TFT-LCD , Assembly |
| Panelgröße | 9.7 inch |
| Auflösung | 1536(RGB)×2048 , QXGA |
| aktiver Bereich | 147.456×196.608 mm |
| Umriss | 167.094×237.618×5.3 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (3H), Antireflection |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | eDP (4 Lanes), 60 pins |
| Eingangsspannung | 3.7V (Typ.) |
| Anwendung | PAD |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPA2 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQE | LG Display | 9.7 | 1024×768 |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| EJ101IA-02A | Innolux | 10.1 | 1280×800 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LD070WX6-SM01 | LG Display | 7.0 | 800×1280 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
