| Artikelnummer | HT260WX1-100 |
| Marke | BOE |
| Größe | 26.0 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 800:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | BOE |
| Panel-Modell | HT260WX1-100 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 26.0 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 575.769×323.712 mm |
| Umriss | 626×373×43.5 mm |
| Oberfläche | Antiglare (Haze 25%), Hard coating (3H) |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + FRC) |
| Reaktionszeit | 5 (Typ.)(G to G) |
| Blickwinkel | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | LCTV |
| HT260WX1-100 | BOE | 26.0 | 1366×768 |
| HT260WX2-101 | BOE | 26.0 | 1366×768 |
| HT260WXC-100 | BOE | 26.0 | 1366×768 |
| LC260EXN-SDA1 | LG Display | 26.0 | 1366×768 |
| LC260WX2-SL01 | LG Display | 26.0 | 1366×768 |
| LTA260AP02 | Samsung | 26.0 | 1366×768 |
| T260XVN01.4 | AUO | 26.0 | 1366×768 |
| T260XW02 V0 | AUO | 26.0 | 1366×768 |
| T260XW03 V2 | AUO | 26.0 | 1366×768 |
| V260B3-LE2 | Innolux | 26.0 | 1366×768 |
| LC420DUE-FGA6 | LG Display | 42 | 1920×1080 |
| LC420EUD-SEF1 | LG Display | 42 | 1920×1080 |
| LC420EUE-SEM4 | LG Display | 42 | 1920×1080 |
| LC420WUE-SAB1 | LG Display | 42 | 1920×1080 |
| LC500EUD-FFF3 | LG Display | 50 | 1920×1080 |
| LK315D3HA9K | SHARP | 31.5 | 1920×1080 |
| LQ197V1LC17 | SHARP | 19.7 | 640×480 |
| LTA460HQ18 | Samsung | 46 | 1920×1080 |
| T500HVN07.5 CELL | AUO | 50 | 1920×1080 |
| V315H3-L02 | Innolux | 31.5 | 1920×1080 |
