| Artikelnummer | HT260WX2-101 |
| Marke | BOE |
| Größe | 26.0 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | LVDS |
| Panel-Marke | BOE |
| Panel-Modell | HT260WX2-101 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 26.0 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 575.769×323.712 mm |
| Umriss | 592×339.8 mm |
| Oberfläche | Antiglare (Haze 25%), Hard coating (3H) |
| Glastiefe | 0.70+0.70 mm |
| Durchlässigkeit | 7.05% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Reaktionszeit | 5 (Typ.)(G to G) |
| Blickwinkel | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
