| Artikelnummer | G156BGE-L01 |
| Marke | Innolux |
| Größe | 15.6 |
| Anwendung | IA |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | |
| CR | |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | INNOLUX |
| Panel-Modell | G156BGE-L01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.6 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 344.232×193.536 mm |
| Umriss | 363.8×215.92×17.35 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | |
| Kontrastverhältnis | |
| Farben anzeigen | 16.7M (8-bit), CIE193165% |
| Reaktionszeit | 3/7 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | IA |
