| Artikelnummer | ER057005NC6 |
| Marke | EDT |
| Größe | 5.7 |
| Anwendung | IA |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 150 |
| CR | 50:1 |
| Farben | Color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Parallel Data |
| Panel-Marke | EDT |
| Panel-Modell | ER057005NC6 |
| Plattentyp | CSTN-LCD , LCM |
| Panelgröße | 5.7 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | STN, Normally Black, Transmissive |
| aktiver Bereich | 115.2×86.4 mm |
| Umriss | 167×109×9.4 mm |
| Oberfläche | |
| Helligkeit | 150 cd/m² (Typ.) |
| Kontrastverhältnis | 50:1 (Typ.) |
| Farben anzeigen | Color |
| Reaktionszeit | 350/250 (Typ.)(Tr/Td) |
| Blickwinkel | 40/40/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | Parallel Data (8-bit), 16 pins |
| Eingangsspannung | 3.3/5.0V (Typ.)(VDD) |
| Anwendung | IA |
