| Artikelnummer | HGS128641-Y-EH-LV |
| Marke | Other |
| Größe | 2.7 |
| Anwendung | IA |
| Auflösung | 128×64 |
| Komposition | OLED |
| Helligkeit | |
| CR | |
| Farben | Mono(Yellow) |
| Hintergrundbeleuchtung | self |
| Schnittstelle | CPU/SPI/I²C |
| Panel-Marke | TSINGTEK |
| Panel-Modell | HGS128641-Y-EH-LV |
| Plattentyp | PM-OLED , OLED |
| Panelgröße | 2.7 inch |
| Auflösung | 128×64 |
| aktiver Bereich | 61.41×30.69 mm |
| Umriss | 85×58×8 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | |
| Farben anzeigen | Mono(Yellow) |
| Blickwinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| Signalschnittstelle | 8-bit 6800/8080 parallel, SPI, I²C, 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
