| Artikelnummer | G185BGE-L01 |
| Marke | Innolux |
| Größe | 18.5 |
| Anwendung | IA |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | CHIMEI INNOLUX |
| Panel-Modell | G185BGE-L01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 18.5 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 409.8×230.4 mm |
| Umriss | 430.37×254.6×16.6 mm |
| Oberfläche | Antiglare (Haze 25%), Hard coating (3H) |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 1.5/3.5 (Typ.)(Tr/Td) |
| Blickwinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | IA |
| G185BGE-L01 | Innolux | 18.5 | 1366×768 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| HT185WX1-300 | BOE | 18.5 | 1366×768 |
| LM185TT2A | PANDA | 18.5 | 1366×768 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLC5 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| V185B1-LE1 | Innolux | 18.5 | 1366×768 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| HT150X02-101 | BOE | 15.0 | 1024×768 |
| KCG075VG2BE-G00 | Kyocera | 7.5 | 640×480 |
| MC57T04L | Other | 5.7 | 320×240 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL6448BC33-20 | NLT | 10.4 | 640×480 |
| NL8060BC31-27D | NLT | 12.1 | 800×600 |
| NL8060BC31-47 | NLT | 12.1 | 800×600 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
