| Artikelnummer | AM-640480G4TNQW-A0H |
| Marke | AMPIRE |
| Größe | 5.7 |
| Anwendung | IA |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 250:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | AMPIRE |
| Panel-Modell | AM-640480G4TNQW-A0H |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.7 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 115.2×86.4 mm |
| Umriss | 127×98.43×7.5 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 250:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 50 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| COM70T7M17ZLC | ORTUSTECH | 7.0 | 800×480 |
| LB104V03-TD01 | LG Display | 10.4 | 640×480 |
| LM32P101 | SHARP | 4.7 | 320×240 |
| LTA121B860F | TOSHIBA | 12.1 | 800×600 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| LTD121C31S | TOSHIBA | 12.1 | 800×600 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
| SX25S004 | KOE | 10.0 | 800×600 |
| TX26D05VM1CAA | KOE | 10.4 | 640×480 |
