| Artikelnummer | TX26D05VM1CAA |
| Marke | KOE |
| Größe | 10.4 |
| Anwendung | IA |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | |
| CR | |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | HITACHI |
| Panel-Modell | TX26D05VM1CAA |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.4 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 211.2×158.4 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | |
| Blickwinkel | |
| Frequenz | 60Hz |
| Lampentyp | 2 pcsCCFL |
| Signalschnittstelle | CMOS (1 ch, 6-bit) |
| rohs: | |
| Anwendung | IA |
| AA104VB04 | Mitsubishi | 10.4 | 640×480 |
| KCB6448BSTT-X1 | Kyocera | 10.4 | 640×480 |
| LM104VC1T51 | SHARP | 10.4 | 640×480 |
| LTD104EDZS | TOSHIBA | 10.4 | 1024×768 |
| LTM10C306Y | TOSHIBA | 10.4 | 1024×768 |
| M104GNX1 R1 | IVO | 10.4 | 1024×768 |
| TX26D01VM1CAA | KOE | 10.4 | 640×480 |
| TX26D02VM1CAA | KOE | 10.4 | 640×480 |
| TX26D05VM1CAA | KOE | 10.4 | 640×480 |
| TX26D06VM1CAA | KOE | 10.4 | 640×480 |
| DLC1210BBG-2 | Other | 12.1 | 800×600 |
| G158ETN01.0 | AUO | 15.8 | |
| LJ640U21 | SHARP | 7.9 | 640×200 |
| LMG7420PLFC-X | KOE | 5.1 | 240×128 |
| LQ121S1DG11 | SHARP | 12.1 | 800×600 |
| LQ121S1LG61 | SHARP | 12.1 | 800×600 |
| NL10276BC20-37 | NLT | 10.4 | 1024×768 |
| PD064VX1 | E Ink | 6.4 | 640×480 |
| TX18D40VM1CAA | KOE | 7.0 | 800×480 |
| TX26D12VM0APA | KOE | 10.4 | 800×600 |
