| Artikelnummer | ED050SC3 |
| Marke | E Ink |
| Größe | 5.0 |
| Anwendung | EBK |
| Auflösung | 800×600 |
| Komposition | EPD |
| Helligkeit | |
| CR | |
| Farben | Grayscale |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | |
| Panel-Marke | PVI |
| Panel-Modell | ED050SC3 |
| Plattentyp | EPD , EPD |
| Panelgröße | 5.0 inch |
| Auflösung | 800×600 , SVGA |
| aktiver Bereich | 101.6×76.2 mm |
| Umriss | 114.6×89.6×1.28 mm |
| Oberfläche | Antiglare, Hard coating |
| Helligkeit | |
| Kontrastverhältnis | 6:1 (Min.)(Reflective) |
| Farben anzeigen | Grayscale (4-bit) |
| Blickwinkel | 90/90/90/90 (Typ.)(L/R/U/D) |
| rohs: | |
| Anwendung | EBK |
