| Artikelnummer | CLAA170EA07 |
| Marke | CPT |
| Größe | 17.0 |
| Anwendung | DMPC |
| Auflösung | 1280×1024 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 500:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | CPT |
| Panel-Modell | CLAA170EA07 2 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 17.0 inch |
| Auflösung | 1280(RGB)×1024 , SXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 337.92×270.336 mm |
| Umriss | 358.5×296.5×17.5 mm |
| Oberfläche | Antiglare |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + FRC), CIE193172% |
| Reaktionszeit | 5/7 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/67/63 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | DMPC |
