| Artikelnummer | CLAA102NC01CW |
| Marke | CPT |
| Größe | 10.2 |
| Anwendung | NOPC |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 500:1 |
| Farben | 262K/16.2M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | CPT |
| Panel-Modell | CLAA102NC01CW |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.2 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 222.72×130.5 mm |
| Umriss | 235×147×5.4 mm |
| Oberfläche | Antiglare |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| Reaktionszeit | 20 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4S6PWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 60 pins |
| Eingangsspannung | 3.3/9.6/18.0/-6.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Anwendung | NOPC |
