| Artikelnummer | NL128102BC23-03 |
| Marke | NLT |
| Größe | 15.4 |
| Anwendung | DMPC |
| Auflösung | 1280×1024 |
| Komposition | LCM |
| Helligkeit | 240 |
| CR | 250:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | NEC |
| Panel-Modell | NL128102BC23-03 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.4 inch |
| Auflösung | 1280(RGB)×1024 , SXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 305.28×244.224 mm |
| Umriss | 340×269 mm |
| Oberfläche | Hard coating (3H), Antireflection |
| Helligkeit | 240 cd/m² (Typ.) |
| Kontrastverhältnis | 250:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + FRC), CIE193160% |
| Reaktionszeit | 6/41 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 50 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | DMPC |
