| Artikelnummer | NL128102BM29-05A |
| Marke | NLT |
| Größe | 19.0 |
| Anwendung | MD |
| Auflösung | 1280×1024 |
| Komposition | LCM |
| Helligkeit | 1000 |
| CR | 900:1 |
| Farben | Grayscale |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | NEC |
| Panel-Modell | NL128102BM29-05A |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 19.0 inch |
| Auflösung | 1280(LCR)×1024 , SXGA |
| Anzeigemodus | SA-SFT, Normally Black, Transmissive |
| aktiver Bereich | 376.32×301.056 mm |
| Umriss | 404.2×330×25.55 mm |
| Oberfläche | Antiglare, Hard coating (2H) |
| Helligkeit | 1000 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | Grayscale (8-bit) |
| Reaktionszeit | 18/17 (Typ.)(Tr/Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| rohs: | |
| Anwendung | MD |
| LM190E08-TLGD | LG Display | 19.0 | 1280×1024 |
| LM190WX1-TLC1 | LG Display | 19.0 | 1440×900 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
| NL128102AC28-07 | NLT | 18.1 | 1280×1024 |
| NL128102AC29-17 | NLT | 19.0 | 1280×1024 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
| NL128102BC29-01 | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01B | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| ITQX21K | IDTech | 20.8 | 2048×1536 |
| ITSX88E | IDTech | 18.1 | 1280×1024 |
| LQ201U1LW31 | SHARP | 20.1 | 1600×1200 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-01A | NLT | 21.3 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| VVX28T143H00 | Panasonic | 28.0 |
